Powered studio monitor with dual 7″ + 3.5″ mid + X-ART tweeter (each)

Our price:$1,999.00 GST
Order Code: A77H

Contact us for expected arrival, queue backorder

ADAM Audio A77H is a powered three-way studio monitor with dual 7″ woofers, 3.5″ midrange, plus a classic X-ART (rotatable) tweeter and waveguide. Each pricing.

A77H delivers an ultra-wide frequency range. The addition of the midrange driver helps produce clear sound in the most sensitive range of human hearing. Rotatable HPS waveguide technology and onboard DSP allow you to tune the sound for your precise requirements.


The ADAM Audio A Series delivers highly accurate, transparent sound across a full line of monitors that can be controlled remotely and in real time. Comprising five models, the A4V, A7V, A44H, A77H and A8H are the right fit for an array of professional and home studios.

Innovations such as rotatable HPS waveguide technology, and DSP-based room correction and voicings enable you to tune speakers for your room and your ears. Upgradeable firmware allows these monitors to evolve, so you can continue to capitalise on future innovations from ADAM Audio.

A77H features:

  • German Handmade Precision X-ART Tweeter with rotatable HPS waveguide
  • 3.5″ DCH Midrange Driver
  • 2 x 7” Woofer (Multi-Layer Mineral)
  • Cumulated Amp. Power Peak: 340 W
  • Frequency Response @ -6 dB: 34 Hz – 45 kHz
  • Max. peak SPL per speaker at 1 m: 106 dB SPL
Tweeter: Rotatable X-ART Tweeter + HPS Waveguide
Mid Range: 3.5″ (Dome Cone Hybrid) with 33 mm / 1.3″ voice coil
Woofer: 2x 7″ MLM woofer with 38 mm / 1.5” voice coil
Frequency response @ -6dB: 34 Hz – 45 kHz
Maximum SPL per speaker at 1 m: 106 dB
AD converter: 24-bit
Internal sample rate: 96 kHz
Amplifier power RMS: 250 W (woofer) + 70 W (mid range) + 20 W (tweeter)
Crossover frequencies: 400 Hz, 3.0 kHz
Power rating: 500 W max
Analogue Input (balanced): 1x XLR
Analogue Input (unbalanced): 1x RCA
Net Weight: 17.1 kg
Cabinet Height x Width x Depth: 236 x 531 x 350 mm
AC Input Voltage: 100 – 240 V, 50/60 Hz
