Austrian Audio OD505

Stage vocal microphone – active dynamic supercardioid

Our price:$549.00 GST
Order Code: OD505

IN STOCK 6 (more can be backordered)

Austrian Audio OD505 supercardioid stage vocal microphone includes the ODC50-SC active dynamic capsule, along with a switchable low-cut filter.

Featuring Austrian Audio’s proprietary Open Acoustics Technology, the OD505 delivers a pristine, natural and resonance-free sound without any colouring.

More on the active dynamic capsule:

The active front capsule requires 48V phantom power and, at 4.4 mV / Pa, has almost the same sensitivity as a condenser microphone.

With its active circuitry, the OD505’s sound is always consistent, regardless of the internal resistance of the microphone preamplifier or length of connecting cables. The passive lower capsule is polarity-rotated, it senses and reduces unwanted handling noise, especially at the lower frequencies.

OD505 also includes another Austrian Audio proprietary development: The 3D Pop Noise Diffuser. This filter is specially designed for the OD505 and effectively reduces the impact of ‘plosives.


Directional characteristic: Supercardioid
Frequency range: 35 Hz – 16 kHz
Sensitivity: 4.4 mV/Pa
Max SPL: 154 dB SPL
Low cut filter: 120 Hz (2nd order)
Impedance: 275 Ω (symmetrical)
Load impedance: > 1 kΩ
Supply voltage: 48 V (< 1 mA)
Main Connector: XLR 3 pin
Dimensions: 194 x 53 x 53 mm
Weight: 340g
