2 channel tracking and mastering compressor with 8 hand-matched Zener diodes

Our price:$4,780.00 GST
Order Code: ZEN

Contact us for expected arrival, queue backorder

IGS Audio ZEN is ‘all you need to compress your mix’

ZEN is unique.

The construction is based on the legendary compressors used in Abbey Road Studios. It’s the musical canon of art used by The Beatles.

The ZEN Compressor audio circuit is based on 14 bi-polar transistors in each channel. The compression is achieved by 8 hand-matched Zener diodes biased by a perfect feedback circuit.



Not the piece of gear you’re looking for?

For more hand-made IGS Audio recording channels and signal processing, check our IGS Audio brand page here

Basic features
All stepped manipulators Yes
HPF Yes, 60, 90, 120, 240Hz
Stereo Link Yes
Hard wire bypass Yes
Compression type Zener diodes
Input & Output
Input Impedance (balanced) 10k Ohm
Output Impedance (balanced) 75 Ohm
Audio transformers Yes, IGS Custom, on inputs and outputs
Operating Level +4 dBu
Dynamic Range >100dB
Noise Level -99dBu
Max. gain 36dB
Max Gain Reduction -35dB
Time constants
Ratio Variable, depends on the input settings, plus Limiter
Attack: 8 – 100 ms, x4 switchable
Release: 10 – 2000 ms, x4 switchable
Frequency response 20 Hz – 20 kHz, +/- 0.1dB
Distortion (@ 20 Hz – 20 kHz)
Signal to Noise Ratio >90dB
THD+N >86dB
Crosstalk 80dB @ 1kHz
Front Panel
VU Meters Yes, GR in dB’s, left & right,
Voltage Selectable 115/230 VAC
Power consumption <30 VAC
Power supply Linear, internal
Packing box
Dimensions 19″ unit
Shipping weight 9 kg
Used for Mastering, tracking
