I/O Box with 16 Remote-Controllable MIDAS Preamps, 8 Outputs and AES50 Networking featuring KLARK TEKNIK SuperMac Technology. Designed to tether happily to Behringer's remarkable X32 digital mixer, S16 has a massive set of product features:
Massive Connectivity
When used as part of a complete X32 system, two S16 Stage Boxes can be cascaded via the built-in AES50 ports, providing connectivity for up to 32 mic/line inputs, 16 balanced outputs and the incredibly-affordable POWERPLAY P-16 Personal Monitoring System, which can feed up to 48 individual monitor mixers. We also included two optical ADAT sockets for connecting channels 1-8 and 9-16 to outboard devices, a convenient USB port for system updates via your PC, plus MIDI I/O for lighting systems and sound module control.
- 16 MIDAS-designed, fully programmable mic preamps for audiophile sound quality
- 8 analog, servo-balanced XLR outputs
- AES50 network ports featuring KLARK TEKNIK’s SuperMAC networking capability for ultra-low jitter and latency
- Up to 100 m networking capability via CAT-5e cable (not included)
- Dual AES50 ports for cascading S16 units—no merger or router required
- Precise LED metering plus 7-segment displays for signal control on stage
- Phones output assignable to any of the inputs/outputs for on-stage monitoring
- Connectivity for BEHRINGER's P-16 Personal Monitoring System for In-Ear applications (not included)
- Dual ADAT outputs for use in splitter mode and stand-alone digital multicore applications
- MIDI In/Out for bi-directional communication between FOH console and on-stage MIDI devices
- USB connector for system updates via PC
- "Planet Earth" switching power supply for maximum flexibility (100 - 240 V~), noise-free audio, superior transient response plus low power consumption for energy saving
- "Built like a tank" yet compact, all-steel 2U rack-mount chassis
- High-quality components and exceptionally rugged construction ensure long life
